• 4× RJ45 Ports: 10/100/1000 Mbps (1× port WAN, 3× port LAN)
• 3G Technology: Up to 42 Mbps
• Teltonika Remote Management System (RMS)
• Processor: MediaTek, Dual-core, 880 MHz, MIPS1004KC
• Digital Input/Output: For remote monitoring and control
• USB A Interface
• Operating System RutOS: Based on OpenWrt
• Multiple Secure VPN Services
• IP Rating: IP30
• Dimensions: 115 × 44.2 × 95.1 mm
• Weight: 457 g
Secure Payment Options
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information. NB: Prices are subject to change without notice
Buy Teltonika RUTM09 4G LTE Industrial Router in Nairobi Kenya
The RUTM09 is an advanced mobile networking device designed for robust and secure connectivity in industrial environments. It features high-speed mobile internet with 4G LTE Cat 6, offering download speeds up to 300 Mbps. Dual SIM capability ensures reliable network access with automatic switching based on signal strength and other conditions. Comprehensive security measures include pre-configured and customizable firewall rules, advanced attack prevention, and support for various VPN protocols such as OpenVPN, IPsec, and WireGuard.
Key Points:
High-Speed Mobile Internet: Supports 4G LTE Cat 6 for up to 300 Mbps download speeds and dual SIM for seamless connectivity.
Comprehensive Security Features: Includes advanced firewall, DDOS prevention, and multiple VPN protocol support.
Industrial-Grade Design: Durable aluminium casing, wide operating temperature range, and multiple mounting options for versatile deployment.
Key Features of the Teltonika RUTM09
5G Connectivity: The RUTM09 supports 5G technology, offering ultra-fast internet speeds and low latency. This makes it suitable for applications that require high bandwidth and real-time data processing.
Dual SIM with Auto Failover: The router features dual SIM slots with auto-failover, backup WAN, and other switching scenarios. This ensures uninterrupted connectivity by automatically switching to a secondary SIM if the primary connection fails.
Gigabit Ethernet Ports: The RUTM09 is equipped with four Gigabit Ethernet ports, providing high-speed wired connections for multiple devices. This is essential for environments that demand stable and fast internet access.
Advanced Security Features: Security is a top priority with the RUTM09. It supports a wide range of VPN services, including OpenVPN, IPsec, PPTP, L2TP, and DMVPN, ensuring secure and encrypted data transmission.
Powerful CPU: The router is powered by a robust CPU, which ensures efficient data processing and smooth operation even under heavy network traffic.
RutOS Software: The RUTM09 runs on RutOS, an advanced operating system based on OpenWrt. RutOS offers a user-friendly interface and a wide range of features, including advanced firewall settings, remote management capabilities, and support for various networking protocols.
Remote Management System (RMS): The RUTM09 is compatible with Teltonika’s Remote Management System, allowing users to monitor and manage their network devices remotely. This feature is particularly useful for large-scale deployments and remote locations.
Wide Power Supply Range: The router supports a wide range of power supply voltages (9-50V), making it versatile and easy to integrate into various industrial environments.
Digital Input/Output and USB Interface: The RUTM09 includes digital input/output for remote monitoring and control, as well as a USB 2.0 interface for additional connectivity options.
Protocol Support: The router supports multiple protocols, including MQTT, Modbus, TCP, BGP, and GRE, making it highly adaptable to different networking requirements.
Conclusion
The Teltonika RUTM09 is a versatile and powerful industrial router that offers high-speed 5G connectivity, advanced security features, and robust performance. Its compatibility with Teltonika’s Remote Management System and support for a wide range of protocols make it an excellent choice for industrial, enterprise, and IoT applications. Whether you need a reliable router for a factory, office, or remote location, the RUTM09 delivers exceptional performance and flexibility.
Teltonika Describes the RUTM09 as:-
The RUTM09 is a wireless 4G LTE router developed for high-cellular-speed applications. It comes with Cat 6 and dual SIM capabilities, enabling the device to support speeds of up to 300 Mbps and functions like carrier aggregation and failover. Additionally, the RUTM09 comes with four Gigabit RJ45 ports and includes GNSS, enabling GPS tracking for precise location detection. These features make the RUTM09 an exceptional choice for ensuring non-interruptible network connectivity for mobile applications or those requiring tracking.
4G LTE Cat 6 up to 300 DL/ 50 UL Mbps; 3G up to 42 DL/ 5.76 UL Mbps
3GPP Release
Release 12
SIM switch
2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail, SIM idle protection
Status
IMSI, ICCID, operator, operator state, data connection state, network type, CA indicator, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC
SMS
SMS status, SMS configuration, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
USSD
Supports sending and reading Unstructured Supplementary Service Data messages
Block/Allow list
Operator block/allow list (by country or separate operators)
Multiple PDN
Possibility to use different PDNs for multiple network access and services
Band management
Band lock, Used band status display
SIM idle protection service
Provides the possibility to configure the router to periodically switch to the unused SIM card and establish a data connection in order to prevent the SIM card from being blocked
SIM PIN code management
SIM PIN code management enables setting, changing, or disabling the SIM card’s PIN
APN
Auto APN
Bridge
Direct connection (bridge) between mobile ISP and device on LAN
Passthrough
Router assigns its mobile WAN IP address to another device on LAN
Ethernet
WAN
1 x WAN port 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
LAN
3 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN
VoIP passthrough support
H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
Connection monitoring
Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection
Firewall
Port forward, traffic rules, custom rules, TTL target customisation
Firewall status page
View all your Firewall statistics, rules, and rule counters
Ports management
View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on
Network topology
Visual representation of your network, showing which devices are connected to which other devices
DHCP
Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards
QoS / Smart Queue Management (SQM)
Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e
DDNS
Supported >25 service providers, others can be configured manually
DNS over HTTPS
DNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS
Network backup
Mobile, VRRP, Wired options, each of which can be used as an automatic Failover
Load balancing
Balance Internet traffic over multiple WAN connections
Hotspot
Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes and optionality to upload and download customised hotspot themes
SSHFS
Possibility to mount remote file system via SSH protocol
VRF support
Initial virtual routing and forwarding (VRF) support
Traffic Management
Real-time monitoring, wireless signal charts, traffic usage history
Security
802.1x
Port-based network access control client
Authentication
Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generator
Firewall
Preconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64
Extract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting, allowing scripts to utilize the router’s Data to server feature
MQTT Gateway
Modbus MQTT Gateway
Allows sending commands and receiving data from MODBUS Server through MQTT broker
DNP3
Supported modes
Station, Outstation
Supported connection
TCP, USB
DLMS/COSEM
DLMS Support
DLMS – standard protocol for utility meter data exchange
Supported modes
Client
Supported connection types
TCP, USB
COSEM
Allows to scan meter COSEM objects for automatic detection and configuration
API
Teltonika Networks Web API (beta) support
Expand your device’s possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation: https://developers.teltonika-networks.com
Monitoring & Management
WEB UI
HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status
FOTA
Firmware update from server, automatic notification
SSH
SSH (v1, v2)
SMS
SMS status, SMS configuration
Call
Reboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer
Email
Receive email message status alerts of various services
SNMP (v1, v2, v3), SNMP Trap, Brute force protection
JSON-RPC
Management API over HTTP/HTTPS
RMS
Teltonika Remote Management System (RMS)
IoT Platforms
ThingWorx
Allows monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
Cumulocity – Cloud of Things
Allows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength. Has reboot and firmware upgrade actions
Azure IoT Hub
Can be configured with Data to Server to send all the available parameters to the cloud. Has Direct method support which allows to execute RutOS API calls on the IoT Hub. Also has Plug and Play integration with Device Provisioning Service that allows zero-touch device provisioning to IoT Hubs
AWS IoT Core
Utility to interact with the AWS cloud platform. Jobs Support: Call the device’s API using AWS Jobs functionality
System Characteristics
CPU
MediaTek, Dual-core, 880 MHz, MIPS1004Kc
RAM
256 MB, DDR3
FLASH storage
16 MB serial NOR flash, 256 MB serial NAND flash
Firmware / Configuration
WEB UI
Update FW from file, check FW on server, configuration profiles, configuration backup
FOTA
Update FW
RMS
Update FW/configuration for multiple devices at once
Keep settings
Update FW without losing current configuration
Factory settings reset
A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer’s configuration
FIRMWARE CUSTOMISATION
Operating system
RutOS (OpenWrt based Linux OS)
Supported languages
Busybox shell, Lua, C, C++
Development tools
SDK package with build environment provided
GPL customization
You can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needs
Package Manager
The Package Manager is a service used to install additional software on the device
